PMA Mid-Atlantic Deep Draw Seminar and Bruderer Plant Tour

next event

Wednesday, May 14, 2025
Ridgefield, NJ

The PMA Mid-Atlantic District invites you to attend a day of presentations from Pete Ulintz and Invernizzi as well as a tour of Bruderer Machinery, Inc.’s New Jersey facility.

Avoiding Self-Inflicted Deep Drawing Problems with Pete Ulintz
Troubleshooting deep drawing problems can be a frustrating experience. For any given problem there can be multiple causes and potentially twice as many solutions. Sophisticated troubleshooting tools are available, including: Circle Grid Analysis (CGA), Forming Limit Diagrams (FLD), Finite Element Methods (FEM), Statistical Deformation Control (SDC), and Design of Experiments (DOE). Unfortunately, many deep draw problems must be solved during production runs when it often is not practical to use analytical tools and methodologies. In these cases, problem solving can be enhanced with a deeper understanding of material properties, mechanics of deformation and material flow.

This presentation will address:
• The effects of tooling geometry on drawability
• Myth-busting (outdated) rules-of-thumb
• Important material property considerations
• Understanding and controlling metal flow
• Identifying root cause (stretching vs. drawing)
• Common problems and potential solutions

MEET THE SPEAKER

https://www.pma.org/public/mid_atlantic/images/peteulintz.png

Peter Ulintz worked in the metal stamping and tool and die industries for 37 years prior to serving as PMA's technical director from July 2015 to May 2024. His background includes tool and die making, die processing and design, engineering management, and product development. Peter now is an industry consultant, training metalforming industry employees at PMA technical seminars and conferences, in addition to providing in-plant training. He is past president of the North American Deep Drawing Research Group, and authors the Tooling by Design column in MetalForming magazine.


ABOUT BRUDERER

https://ebusiness.pma.org/ProductImages/113221891.Def.L.png"

Bruderer Machinery, Inc. is world-renowned as a pacesetter in high-quality punching technology. Founded in 1964 by Alois K Rupp, the company took just a few years to develop from humble beginnings into an international company. This tremendous success has been made possible by four company traits, which have all become Bruderer Machinery, Inc. trademarks: performance, precision, quality and service. Today, the company has evolved from a high-speed stamping machine sales outlet to a supplier of complete complex stamping lines.


AGENDA

  • 10:30 a.m.    Pete Ulintz to present first session
  • 12:00 p.m.    Lunch to be served
  • 1:00 p.m.      Pete Ulintz to present second session
  • 2:00 p.m.      Coffee break
  • 2:30 p.m.      Invernizzi presentation
  • 3:30 p.m.      Bruderer tour
  • 5:00 p.m.      Light dinner and drinks

LOCATION

  • Bruderer Machinery, Inc.
    1200 Hendricks Causeway
    Ridgefield, NJ 07657

REGISTRATION INFORMATION

  • PMA Member: Free
  • Nonmember: Free

NOTICE:
In order to avoid a known bug found with the Chrome browser, please use the latest version of Microsoft Edge or FireFox when registering.
If you are not attending, but need to register others.
